SIG Sauer ALPHA3 34mm Scope Mount, 20 MOA, 1.535 in, Black

Description

SIG Sauer ALPHA3 34mm Scope Mount, 20 MOA, 1.535 in, Black

The SIG ALPHA3 34mm 1.535 in. 20 MOA scope mount is SIG’s 7075-T6 extra-high Picatinny mount for 34 mm tubes at 1.535 in. and 20 MOA.

The SIG ALPHA3 is SIG’s one-piece 7075-T6 Picatinny scope mount. Height is 1.375 in. or 1.535 in. from the centerline of the optic to the top of the rail. Cant is 0 MOA or 20 MOA. Tube diameter is 30 mm or 34 mm. Finish is black or FDE. Rail torque is 65 in-lb. Scope-cap torque is 25 in-lb on T15 screws.

ALPHA3 uses 7075-T6 aluminum. 1.375 in. is the lower 30 mm 0 MOA mount. 1.535 in. is extra-high. 20 MOA is only on the 20 MOA mounts. FDE is a finish, not a different height. Tube diameter has to match the riflescope. Rail torque is 65 in-lb. Scope-cap torque is 25 in-lb on T15 screws.

This ALPHA3 34mm 20 MOA

This mount uses a 34 mm tube, a 1.535 in. extra-high height, and 20 MOA of cant. Finish is black.

What ships

The mount is in the box.

Specifications and Included Items

• Model: SOA30007
• Tube: 34 mm
• Height: 1.535 in extra-high
• Cant: 20 MOA
• Material: 7075-T6
• Finish: Black
