Trijicon HD Night Sight Set for Springfield XD, Yellow Front Outline

Description

Trijicon HD Night Sight Set for Springfield XD, Yellow Front Outline

The Trijicon SP101Y HD night sight set is the yellow front-outline version for compatible Springfield Armory XD-family pistols. The front and rear lamps glow green, with a black-outlined U-notch rear sight completing the pair.

Trijicon lists XD, XD-M, and XD Mod. 2 fitment for this SP101 configuration and excludes OSP models. The XD-S and XD-E use the separately specified SP102 family, so the XD name alone should not be used to choose between these sets.

The front blade is 0.200 in. high and carries a photoluminescent ring around its tritium lamp. The rear blade measures 0.218 in. high, with a notch 0.169 in. wide. All three lamps illuminate without batteries, and protective aluminum cylinders, silicone cushioning, and sapphire caps surround the illuminated elements.

Specifications

• Model: SP101Y
• Item number: 600583
• Compatibility: Springfield Armory XD, XD-M, and XD Mod. 2; excludes OSP models
• Included sights: Front and rear
• Front outline: Yellow photoluminescent paint
• Tritium lamp color: Green front and rear
• Rear outline and notch: Black outline; U-shaped notch
• Front blade width: 0.144 in. (3.65 mm)
• Front blade height: 0.2 in. (5.08 mm)
• Overall front blade height: 0.264 in. (6.7 mm)
• Rear notch width: 0.169 in. (4.29 mm)
• Rear blade height: 0.218 in. (5.53 mm)
• Overall rear height: 0.309 in. (7.84 mm)
