Description
Trijicon 30mm Q-LOC Bolt-Action Scope Mount, 1.06-Inch Height
The AC22045 is the lower 30 mm Q-LOC bolt-action mount, placing the scope’s optical axis 1.06 inches above the rail. Its compact, non-cantilever layout suits scopes that do not need a forward-offset mounting position. Trijicon lists this model for objective lenses up to 42 mm, subject to the actual scope housing and rifle clearance.
The 6061-T6 aluminum body joins both rings on one base. Spring-loaded Q-LOC rail attachment provides quick-release convenience, while the matte black anodized finish keeps the appearance subdued. This 1.06-inch model is distinct from the taller AC22044; choose the height around the complete scope dimensions and stock fit, not tube diameter alone.
Specifications
- Manufacturer part number: AC22045
- Scope tube diameter: 30 mm
- Mount style: Q-LOC bolt-action
- Optical-axis height above the rail: 1.06 inches
- Rail compatibility: MIL-STD-1913 / NATO Picatinny
- Material: 6061-T6 aluminum
- Finish: matte black anodized
- Manufacturer-listed objective lens size: up to 42 mm; actual clearance depends on the scope and firearm
- Includes: one mount, two ring caps, eight screws, and one hex key
